1.Adopt super quality thermal insulation material inside of the furnace. It is not easy ageing, deformed, residue, insure the optical result on the glass surface and continue the lifetime of the funace.
2.To use long life time and reliable heating elements, without the welding spot in the middle and hard to burn-out.
3.Adopt synchronuous processing forming way technology for glass forming more suitable for the bent tempering section.
4.Adopt special design and process in roller support so that it is easy to dismantle, assamble and the whole line is even and no drift during the tempering process.
5.Has excellent human-machine interface.
6.Reasonable fan collocate and high quality thermal insulation material for less power consumption.
Quality Assurance
1. CN, CE or UL Standard.
2. The warranty is valid within one year from installation.
3. The spare parts due to quality or design problem, we will change it free of charge or in case of necessary, we will send our technician/engineer to the buyer factory for repairing it and related labor cost, we will cover it.
| Max flat glass size | 4 - 250 mm |
|---|---|
| Max bent glass size | 2400*1500mm |
| Min flat glass size | 150*300 mm |
| Min bent glass size | 200*350mm |
| Flat glass thickness | 4~19 mm |
| Bent glass thickness | 4-12 mm |
| Min bent glass radius | 750mm |
| Flat glass productivity | 110 m2/h |
| Bent glass productivity | 35 m2/h |
| Installed power | 900KW |
