Quality Assurance
1. CN, CE or UL Standard.
2. The warranty is valid within one year from installation.
3. The spare parts due to quality or design problem, we will change it free of charge or in case of necessary, we will send our technician/engineer to the buyer factory for repairing it and related labor cost, we will cover it.
| JJ2200 | JJ2200 | JJ2800 | JJ3300 | ||
|---|---|---|---|---|---|
| JJE2200 | JJE2600 | JJE2800 | JJE3300 | ||
| Max.working width | mm | 2200 | 2600 | 2800 | 3300 |
| Max.glass length | mm | 4000(A1) | 6000(A2) | 6000(A2) | 6000(A2) |
| Min glass size | mm | 400*600 | 500*800 | 500*1000 | 500*1000 |
| Glass thickness | mm | 43178 | 43178 | 43178 | 43178 |
| Max thickness of laminated glass | mm | 60 | 60 | 60 | 60 |
| PVB rolls unit | Rolls | 3(B) | 3(B) | 3(B) | 3(B) |
| PVB laying and cutting system | MANUAL OR AUTO MATIC | ||||
| Production capacity(single layer) | m²/8h | 800 | 1000 | 1300 | 1700 |
| Working height | mm | 890±30 | 890±30 | 890±30 | 890±30 |
| Power (without Autoclave) | kw | 160 | 190 | 230 | 280 |
